Panorama

  • a three chamber door system with thermal insulation used to design folding doors
  • it is possible to use two types of the threshold system: the flat-threshold system
  • is equipped with a brush seal and an air-tight threshold whose design is based on a frame around the perimeter of the entire terrace window
  • depending on requirements and the application, the Panorama systems offers inswing or outswing structures; there are many leaf combinations available (2+1, 3+2, 3+3)
  • new integrated hardware, such as hinge with bottom carriage, hinge with pull handle and low-profile handles, improve structure functionality, with reduced overall dimensions of the assembled accordion door structure at the same time
  • with the minimised visual width of the profile available in the system, the design of folding doors appears to be a light structure
  • the system Panorama is optionally available with improved thermal performance due to additional thermal inserts on the perimeter as well as between door leaf separators and door frames; available options: Panorama i, Panorma i +
  • the folding system is used to provide an aesthetic, functional and user-friendly installation, which at the same time offers very efficient use of the space inside the building
  • a wide range of available solutions and potential applications makes it possible to design structures for balconies, terraces or winter gardens, and even structures perfect for public and commercial buildings
  • there is possibility of use Flyscreen system (Flyscreen – fly screens are a practical andan extremely functional protection against insects)
  • a wide range of colours – RAL palette (Qualicoat 1518), texture colours, Aliplast Wood Colour Effect (wood-like colours), Aliplast Loft View – colours imitating stone surfaces (Qualideco PL-0001), anodised colour (Qualanod 1808), bi-colour
TECHNICAL SPECIFICATION
SYSTEM MATERIAL DEPTH OF FRAME DEPTH OF LEAF GLAZING RANGE ACOUSTIC TYPE OF WINDOWS TYPE OF DOORS
DV aluminium/polyamid 74,5 mm 16-50 mm to 100 kg folding doors
DV i+ aluminium/polyamid 74,5 mm 16-50 mm to 100 kg folding doors
PERFORMANCE
SYSTEM THERMAL INSULATION UF* AIR PERMEABILITY WINDLOAD RESISTANCE WATERTIGHTNESS
DV Uf from 1,68 W/m2K Class 2; EN 12207 C1 (400 PA); EN 12210 Class E1050; EN 12208
DV i+ Uf from 1,33 W/m2K Class 2; EN 12207 C1 (400 PA); EN 12210 Class E1050; EN 12208

*Thermal insulation is dependent on a combination of profiles and thickness of the filling

FILES TO DOWNLOAD

Leaflet Panorama
